Air Die Lifters
Pacesetter Systems Manufactures the Worlds Strongest Quick Die Change Systems and Air Die Lifters


A versatile clamp for use with die ledges of varying thickness.  Ideal for shops using different size dies on the same press.  A large grip range and safety locks allow you to lock the load down tight even if the hydraulic system is disconnected.  Available in three sizes with clamping forces up to 15,000 lbs.

Model
No.

Clamping Force
@ 6,000 PSI

Width

Height

Grip Range

Length

210

4,000 lbs.

2.00

3.34

.75 - 1.75

6.40

220

10,000 lbs.

2.50

5.00

.75 - 2.25

8.84

230

15,000 lbs.

3.00

6.10

1.00 - 3.00

11.14


View a demonstration!
Play Video

A low profile clamp for applications requiring high clamping force. Ideal for shops using dies with a uniform height clamping ledge.  Available in three sizes with clamping forces up to 20,000 lbs.

Model
No.

Clamping Force
@ 6,000 PSI

Width

Height

Grip Range

Length

351

5,000 lbs.

2.00

2.27

.75 - 1.25

4.40

352

10,000 lbs.

3.00

2.27

.75 - 1.25

4.40

354

20,000 lbs.

4.79

2.87

1.00 - 1.50

5.60

A low profile clamp for applications requiring maximum clamping force. Optimum for slide-in dies with uniform clamping ledges. Heavy duty load holding capacity with up to 40,000 of clamping force.  Complete hands-free operation with minimal die standardization required.

Part Number

Grip Range

Height

10452-1.25

1.00 / 1.25

3.38

10452-1.50

1.25 / 1.50

3.63

10452-1.75

1.50 / 1.75

3.88

10452-2.00

1.75 / 2.00

4.13

View a slide-show!
Play Video

A high force clamp with minimum space requirements. For use with slot-type die shoes with consistent height.  An economical and versatile clamping system with T-nut shaft or threaded shaft for easy installation  Available in three models with clamping forces up to 22,000 lbs.

Model
No.

Clamping Force
@ 6,000 PSI

Cylinder
Diameter

Cylinder
Height

Clamp
Stroke

Mechanical
Lock

Installation

240

9,000 lbs.

2.00

2.62

.25

Yes

T-Nut

241

9,000 lbs.

2.00

2.00

.25

No

T-Nut

245

9,000 lbs.

2.00

2.85

.25

No

Threaded Shaft

260

12,000 lbs

2.50

2.73

.31

Yes

T-Nut

261

12,000 lbs.

2.50

2.06

.31

No

T-Nut

265

12,000 lbs.

2.50

2.96

.31

No

Threaded Shaft

280

22,000 lbs.

3.00

3.81

.38

Yes

T-Nut

281

22,000 lbs.

3.00

2.88

.38

No

T-Nut

285

22,000 lbs.

3.00

4.04

.38

No

Threaded Shaft
